Patriot Latitude Tires

Jeep Patriot Latitude is one of the three popular trim levels this SUV was available in. It can be hardly called luxury version of the Patriot, yet it features everything needed for convenient daily drive and can even be modified for further off-road usage. Literary, the Latitude is in the middle in the Patriot scale, between the Sport and Limited Edition. Continue reading to find out specifications and features of the Jeep Patriot in Latitude trim level for different model years!

jeep patriot latitude

Technical Specs of the Jeep Patriot Latitude

As a rule, different model years of the same generation of the American-built car, truck or SUV do not differ a lot in such major things, as type of transmission, engine, platform, etc. Jeep Patriot is not an exception. Below is the chart that explains the main technical specs of this SUV.

Engine2.4 L World I4 (4x4)
2.0 L World I4 (4x2)
Type of fuelgasoline
TransmissionCVT JF011E automatic transmission
Body style4-door SUV
ClassSmall SUV
Drive4x2 or 4x4
AssemblyUSA, Belvidere, IL
PlatformChrysler PM/MK
Power output172 hp (128 kW)
Torque165 lb/ft (224 N/m)

Jeep Patriot Latitude Tires: Sizes & Specs

Even though the interior and exterior details slightly changed for the Jeep Patriot over time when it was in production, the tire size remained standard. The Patriot in this trim level came equipped with 215/60R17 or 15/65R17 wheels from the factory. Follow the link below to find the tires for your Jeep Patriot Latitude .

SHOP NOW

Access our store as a guest!

Jeep Patriot Latitude: Features & Factory Equipment

This trim level of the Jeep Patriot came equipped with certain interior, exterior and security features from the factory. See the list below for detailed information.

Stereo & Electronics:

  • SIRIUS-XM satellite radio;
  • air conditioning with manual control;
  • CD/MP3 stereo.

Interior & Upholstery:

  • power windows;
  • one-touch driver’s auto down feature;
  • power door locks;
  • leather-wrapped steering wheel;
  • cloth seats.

Security & Options:

  • keyless entry;
  • panic feature and security system.

SHOP NOW

Check rating, price & availability!

A common challenge when buying tires is understanding the different types of tires, and which one will work best for you.

understanding-tires

The most popular manufacturers use common tire size abbreviations. They are the same for all tire brands produced throughout the world. When selecting tires for your car, truck or SUV it is a good idea to understand what the sidewall markings mean, in order to understand specs of the tires you select.

Tire Codes Explanation

The first number one can normally see on a tire sidewall is the tire width (in millimeters). In the example above, the tire width is 195 mm. This is a measurement between the sides of tire, from one sidewall to another. Some tire brands use extra letter before the number that denotes width. In the example above, the letter is missing. However, if you see P195, this is a passenger tire that is 195 mm wide. As a rule, width on the sidewall is followed by a slash (/) or a space.
Aspect ratio follows the width in the common tire codes. Sometimes, tire manufacturers can use a space or slash mark between them. Aspect ratio is the second number you can see on the tire sidewall. It explains, how tall is the tire profile. In the example above, aspect ratio equals to 65. Modern tire codes deliver the aspect ratio as percentage. It is calculated by dividing the height of the tire by its width. If you see, that aspect ratio is 65, it means that the height of the tire is 65% of its width. In general, the lower aspect ratio (around 60) means better handling.
Construction type is the letter that follows the aspect ratio in the tire code. It denotes the type of the tire internal construction, that maintains the tire stability on the road. There are 2 types of construction:
  1. R - Radial;
  2. D - Diagonal (also known as Bias Ply).
The majority of tires used in the U.S. are radial tires, and that is the only kind of construction offered by Fuzion tires. So chances are high, that you also have got radial tires on your daily driver. This construction means, that the internal ply cords of the tire are positioned in radial direction, perpendicular to the rotation axis and placed from one bead over to the other.
Explanation of rim diameter is pretty simple, especially for the Americans, who normally use inches to measure something. So, the number, that follows construction type on the tire code, is the diameter of the rim in inches. In the example provided, the code says ‘R15’, which means the rim diameter is 15 inches.
Load index is the combination of digits that follows the rim diameter. It tells, how much weight a tire can support when it is completely inflated (weight in lbs). This measurement is called as load index, since it does not give the exact weight the tire is developed to carry, but it corresponds to certain capacity as an index. You can find a number from 1 to 150, which represents load capacities between 99 and 735 lbs.
Speed rating is the last letter in the tire codes. It works exactly as the load index does for the particular load. This means, that speed rating letter corresponds to a certain speed capability from the internationally standardized base. In the example above, the speed rating is ‘H’. Alternatively, it can be ‘R’ for tires rated up to 106 mph, or ‘S’ for the tires rated for up to 112 mph. Note, that this is not recommended cruising speed, but the speed limit that should not be exceeded for certain tires. The higher speed rating is, the better is handling performance tires offer. If you happen to use tires with different speed ratings on one vehicle, the least speed rating should not be exceeded.

Jeep Patriot Tires

Whether you own Jeep Patriot Sport, Limited or Latitude, it's good to know, what wheel and tire sizes are recommended for your specific vehicle. We have selected all necessary information about these trim levels to let you know about the features, that came standard for these SUVs. Select the trim level you are interested in and find out technical details about Jeep Patriot tires that are guaranteed to work. And if you are a DIY enthusiast and were looking for a quality solution for your shop or garage, we've got a recommendation for you. Check out husky tool box for truck and benefit from quality materials and workmanship from the official manufacturer.







jeep patriot sport

Jeep Patriot Sport
jeep patriot latitude

Jeep Patriot Latitude
jeep patriot limited

Jeep Patriot Limited

★ ★ ★
